TROPO-10 // 650 Watts RMS 10 Inch Car Subwoofer
You Save 23% ($30.00)
Built to bring you the bass you need without breaking the bank you love, the CT Sounds Tropo 10 Inch 650W RMS Car Subwoofer allows you to peer into the atmospheric pressure CT Sounds subwoofers are capable of. Whether you want to fill in the lows in your stereo or drive the neighbors up a wall; the CT Sounds Tropo 10 is the perfect match.
The subwoofer features a 2.5 inch - 4 layer high-temperature copper voice coil, double slug Y30 grade optimized motor, stamped steel basket, flexible high foam surround, dual round weaved copper tinsel leads, and a premium grade spider pack. Boasting a conservative rating of 650 Watts RMS, this 10-inch subwoofer was engineered to be a harmonious combination of price and performance without a compromise on quality.
Looking to show your friends what real bass sounds like? You have come to the Troposphere; bass yourself seven miles up in the atmosphere with explosive sound pressure, the CT Sounds Tropo 10 Inch Subwoofer fills in the bass missing from your current stereo.
| Quick Facts: | |
| RMS Power: | 650 Watts |
| MAX Power: | 1300 Watts |
| Voice Coil Configuration: | Dual 2 Ohm |
| Push Terminal Size: | 12 Gauge |
- 10 Inch Dual 2 Ohm Coil Configuration
- RMS Power: 650 Watts
- MAX Power: 1300 Watts
- 2.5 Inch - 4 Layer High-Temperature Copper Voice Coil
- Y30 Graded Double Stacked Ferrite Magnet
- Flexible High Foam Surround
- Composite Paper with 3% Carbon Fiber Reinforcement
- Signature Chrome Plated Low Carbon Iron Bottom Plate
- Advanced Air Cooling System
- Dual Round Weaved Copper Tinsel Leads
- 12 Gauge Push Terminals
- Fs: 41.80 Hz
- Qms: 6.58
- Qes: 0.67
- Qts: 0.61
- Vas: 15.38 L
- Cms: 0.08 mm/N
- Mms: 176 gr
- Sd: 363 cm²
- Re: 1.08
- Le: 0.59
- BI: 8.60 n/a
- Sensitivity: 86.24 dB
- Xmax: 11mm (one-way)
| Subwoofer Measurements: | |
| Cutout diameter | 8.98" |
| Overall diameter | 10.85" |
| Mounting depth | 5.63" |
| Box Specifications: | |
| Port Area | 24 in2 |
| Displacement | 0.10 ft3 |
| Flat Response Curve (SQ): | |
| Sealed | 0.8 ft3 |
| Ported | 1 ft3 |
| Tuning Frequency | 36 Hz |
| Boomer Response Curve (SPL): | |
| Sealed | - |
| Ported | 1.5 ft3 |
| Tuning Frequency | 35 Hz |
*Flat response curve (SQ) is geared towards people looking for responsiveness. This style box is loud on all frequencies, generates little impedance loss, and can utilize an amplifier rated at the same RMS as the subwoofer.
*Boomer response curve (SPL) is geared towards people looking for maximum loudness. This style box will be louder than the flat response curve at some frequencies, has a high impedance rise, and can utilize an amplifier rated at a slightly higher RMS than the subwoofer.
*Enclosure recommendations do not account for subwoofer, bracing, and port displacement.
Built to bring you the bass you need without breaking the bank you love, the CT Sounds Tropo 10 Inch 650W RMS Car Subwoofer allows you to peer into the atmospheric pressure CT Sounds subwoofers are capable of. Whether you want to fill in the lows in your stereo or drive the neighbors up a wall; the CT Sounds Tropo 10 is the perfect match.
The subwoofer features a 2.5 inch - 4 layer high-temperature copper voice coil, double slug Y30 grade optimized motor, stamped steel basket, flexible high foam surround, dual round weaved copper tinsel leads, and a premium grade spider pack. Boasting a conservative rating of 650 Watts RMS, this 10-inch subwoofer was engineered to be a harmonious combination of price and performance without a compromise on quality.
Looking to show your friends what real bass sounds like? You have come to the Troposphere; bass yourself seven miles up in the atmosphere with explosive sound pressure, the CT Sounds Tropo 10 Inch Subwoofer fills in the bass missing from your current stereo.
| Quick Facts: | |
| RMS Power: | 650 Watts |
| MAX Power: | 1300 Watts |
| Voice Coil Configuration: | Dual 4 Ohm |
| Push Terminal Size: | 12 Gauge |
- 10 Inch Dual 4 Ohm Coil Configuration
- RMS Power: 650 Watts
- MAX Power: 1300 Watts
- 2.5 Inch - 4 Layer High-Temperature Copper Voice Coil
- Y30 Graded Double Stacked Ferrite Magnet
- Flexible High Foam Surround
- Composite Paper with 3% Carbon Fiber Reinforcement
- Signature Chrome Plated Low Carbon Iron Bottom Plate
- Advanced Air Cooling System
- Dual Round Weaved Copper Tinsel Leads
- 12 Gauge Push Terminals
- Fs: 41.50 Hz
- Qms: 5.67
- Qes: 0.69
- Qts: 0.62
- Vas: 16.75 L
- Cms: 0.09 mm/N
- Mms: 164 gr
- Sd: 363 cm²
- Re: 1.83
- Le: 0.83
- BI: 10.60 n/a
- Sensitivity: 86.42 dB
- Xmax: 11mm (one-way)
| Subwoofer Measurements: | |
| Cutout diameter | 8.98" |
| Overall diameter | 10.85" |
| Mounting depth | 5.63" |
| Box Specifications: | |
| Port Area | 24 in2 |
| Displacement | 0.10 ft3 |
| Flat Response Curve (SQ): | |
| Sealed | 0.8 ft3 |
| Ported | 1 ft3 |
| Tuning Frequency | 36 Hz |
| Boomer Response Curve (SPL): | |
| Sealed | - |
| Ported | 1.5 ft3 |
| Tuning Frequency | 35 Hz |
*Flat response curve (SQ) is geared towards people looking for responsiveness. This style box is loud on all frequencies, generates little impedance loss, and can utilize an amplifier rated at the same RMS as the subwoofer.
*Boomer response curve (SPL) is geared towards people looking for maximum loudness. This style box will be louder than the flat response curve at some frequencies, has a high impedance rise, and can utilize an amplifier rated at a slightly higher RMS than the subwoofer.
*Enclosure recommendations do not account for subwoofer, bracing, and port displacement.
