Regular price 29% OFF Before: $139.99 Sale pricePrice: $99.99
/
$99.99
COIL CONFIGURATION
Details

CT Sounds is proud to introduce the hydro shallow mount subwoofer series after completing a rigorous R&D process spanning 2 years! Our goal was to engineer a 500-watt 10” shallow-mount subwoofer with a mounting depth below 4” that was suitable for both sealed & ported enclosures. To achieve this, we focused on the EBP (Efficiency Bandwidth Product). As a general rule, EBP < 50, is used only for sealed enclosures, EBP 50 - 100, is used for both, and EBP > 100, is used only for ported enclosures. EBP = FS/QES.

Quick Facts:
RMS Power: 500 Watts
MAX Power: 1000 Watts
Voice Coil Configuration: Dual 2 Ohm
Use Cases: Sealed & Ported Enclosures

Our 1st prototype utilized a 61.1 mm voice coil & 50 oz magnet resulting in a high QES rating of 0.915 and low EBP of 39.46. The 2nd prototype utilized a 50.8 mm voice coil & 50 oz magnet resulting in a slightly lower QES rating of 0.736 and a slightly higher EBP of 49.27. After the 1st and 2nd prototypes, we determined a larger motor assembly was needed to provide a more controlled electrical system (lower QES). This led us to invest in a custom-tooled basket (used in the final prototype) to keep the mounting depth below 4”.

The 3rd and final prototype uses a 61.1 mm voice coil & 70 oz magnet resulting in a reduced QES rating of 0.504 and a balanced EBP of 76.29. In testing, we ran into mechanical noise due to the larger motor assembly and voice coil in a confined space. Therefore, we invested in a custom-tooled cone to maximize the excursion capability by creating an equal distance between the cone, spider, and bottom plate. The result is a 10” shallow-mount subwoofer that is extremely responsive in both sealed & ported enclosures.

Specs
General Specifications:
Product Type: Car Subwoofer
Subwoofer Size: 10"
Voice Coil Configuration: Dual 2 Ohm
RMS Power: 500 Watts
MAX Power: 1000 Watts
Voice Coil Type: 2.40 Inch - 4 Layer High-Temperature Copper Voice Coil
Magnet Type: Y35
Bottom Plate Type: Low Carbon Iron
Surround Type: Dual White Stitched Competition Mega Foam Surround
Cone Type: Composite Paper with 3% Carbon Fiber Reinforcement
Tinsel Lead Type: Single Braided Flat Copper Tinsel Leads
Terminal Type: 12 Gauge Push Terminals
Basket Type: Stamped Steel
Spider Material: Poly-Cotton Blend
T/S Parameters:
Qes: 0.504
Qms: 5.837
Qts: 0.465
Fs: 38.45 Hz
Vas: 19.878 L
Mms: 152.787 g
Cms: 0.112 m/N
Re: 3.9 Ω
Bl: 16.889 Tm
Le: /
Sd: 356 cm²
Xmax - Single Way (mm): 10 mm
Xmax - Single Way (cm): 1 cm
Vd (Sd*Xmax): 356 cm²
SPL: 85.52 dB
Box Specs
Subwoofer Measurements:
Cutout diameter 9.3"
Overall diameter 10.86"
Mounting depth 3.89"
Box Specifications:
Displacement 0.04 ft3
Box Recommendations:
Sealed 0.5 ft3
Ported 1 ft3
Tuning Frequency 34 Hz
Port Area 16 in2

*Enclosure recommendations do not account for subwoofer, bracing, and port displacement.

Details

CT Sounds is proud to introduce the hydro shallow mount subwoofer series after completing a rigorous R&D process spanning 2 years! Our goal was to engineer a 500-watt 10” shallow-mount subwoofer with a mounting depth below 4” that was suitable for both sealed & ported enclosures. To achieve this, we focused on the EBP (Efficiency Bandwidth Product). As a general rule, EBP < 50, is used only for sealed enclosures, EBP 50 - 100, is used for both, and EBP > 100, is used only for ported enclosures. EBP = FS/QES.

Quick Facts:
RMS Power: 500 Watts
MAX Power: 1000 Watts
Coil Configuration: Dual 4 Ohm
Use Cases: Sealed & Ported Enclosures

Our 1st prototype utilized a 61.1 mm voice coil & 50 oz magnet resulting in a high QES rating of 1.03 and low EBP of 38.22. The 2nd prototype utilized a 50.8 mm voice coil & 50 oz magnet resulting in a slightly lower QES rating of 0.831 and a slightly higher EBP of 47.37. After the 1st and 2nd prototypes, we determined a larger motor assembly was needed to provide a more controlled electrical system (lower QES). This led us to invest in a custom-tooled basket (used in the final prototype) to keep the mounting depth below 4”.

The 3rd and final prototype uses a 61.1 mm voice coil & 70 oz magnet resulting in a reduced QES rating of 0.569 and a balanced EBP of 69.19. In testing, we ran into mechanical noise due to the larger motor assembly and voice coil in a confined space. Therefore, we invested in a custom-tooled cone to maximize the excursion capability by creating an equal distance between the cone, spider, and bottom plate. The result is a 10” shallow-mount subwoofer that is extremely responsive in both sealed & ported enclosures.

Specs
General Specifications:
Product Type: Car Subwoofer
Subwoofer Size: 10"
Voice Coil Configuration: Dual 4 Ohm
RMS Power: 500 Watts
MAX Power: 1000 Watts
Voice Coil Type: 2.40 Inch - 4 Layer High-Temperature Copper Voice Coil
Magnet Type: Y35
Bottom Plate Type: Low Carbon Iron
Surround Type: Dual White Stitched Competition Mega Foam Surround
Cone Type: Composite Paper with 3% Carbon Fiber Reinforcement
Tinsel Lead Type: Single Braided Flat Copper Tinsel Leads
Terminal Type: 12 Gauge Push Terminals
Basket Type: Stamped Steel
Spider Material: Poly-Cotton Blend
T/S Parameters:
Qes: 0.569
Qms: 5.762
Qts: 0.518
Fs: 39.37 Hz
Vas: 20.596 L
Mms: 140.610 g
Cms: 0.116 m/N
Re: 6.6 Ω
Bl: 20.089 Tm
Le: /
Sd: 356 cm²
Xmax - Single Way (mm): 10 mm
Xmax - Single Way (cm): 1 cm
Vd (Sd*Xmax): 356 cm²
SPL: 85.47 dB
Box Specs
Subwoofer Measurements:
Cutout diameter 9.3"
Overall diameter 10.86"
Mounting depth 3.89"
Box Specifications:
Displacement 0.04 ft3
Box Recommendations:
Sealed 0.5 ft3
Ported 1 ft3
Tuning Frequency 34 Hz
Port Area 16 in2

*Enclosure recommendations do not account for subwoofer, bracing, and port displacement.
