TROPO-12 // 650 Watts RMS 12 Inch Car Subwoofer

Regular price 20% OFF Before: $149.99 Sale pricePrice: $119.99
/
$119.99
COIL CONFIGURATION
Details

Built to bring you the bass you need without breaking the bank you love, the CT Sounds Tropo 10 Inch 650W RMS Car Subwoofer allows you to peer into the atmospheric pressure CT Sounds subwoofers are capable of. Whether you want to fill in the lows in your stereo or drive the neighbors up a wall; the CT Sounds Tropo 10 is the perfect match.

The subwoofer features a 2.5 inch - 4 layer high-temperature copper voice coil, double slug Y30 grade optimized motor, stamped steel basket, flexible high foam surround, dual round weaved copper tinsel leads, and a premium grade spider pack. Boasting a conservative rating of 650 Watts RMS, this 10-inch subwoofer was engineered to be a harmonious combination of price and performance without a compromise on quality.

Looking to show your friends what real bass sounds like? You have come to the Troposphere; bass yourself seven miles up in the atmosphere with explosive sound pressure, the CT Sounds Tropo 10 Inch Subwoofer fills in the bass missing from your current stereo.

Quick Facts:
RMS Power: 650 Watts
MAX Power: 1300 Watts
Voice Coil Configuration: Dual 2 Ohm
Push Terminal Size: 12 Gauge
Specs
General Specifications:
Product Type: Car Subwoofer
Subwoofer Size: 12"
Voice Coil Configuration: Dual 2 Ohm
RMS Power: 650 Watts
MAX Power: 1300 Watts
Voice Coil Type: 2.5 Inch - 4 Layer High-Temperature Copper Voice Coil
Magnet Type: Double Stacked Y30 Ferrite Magnet
Bottom Plate Type: Signature Chrome Low Carbon Iron Bottom Plate
Surround Type: Dual White Stitched High Narrow Foam Surround
Cone Type: Composite Paper with 3% Carbon Fiber Reinforcement
Tinsel Lead Type: Dual Round Weaved Copper Tinsel Leads
Terminal Type: 12 Gauge Push Terminals
Basket Type: Stamped Steel
Spider Material: Poly-Cotton Blend
T/S Parameters:
Qes: 0.621
Qms: 6.246
Qts: 0.565
Fs: 32.5 Hz
Vas: 44.33 L
Mms: 215.96 g
Cms: 0.11 m/N
Re: 1.12 Ω
Bl: 8.915 Tm
Le: 0.583 mH
Sd: 530.93 cm²
Xmax - Single Way (mm): 11 mm
Xmax - Single Way (cm): 1.1 cm
Vd (Sd*Xmax): 584.02 cm³
SPL: 87.91 dB
Box Specs
Subwoofer Measurements:
Cutout diameter 10.98"
Overall diameter 12.82"
Mounting depth 6.26"
Box Specifications:
Port Area 32 in 2
Displacement 0.13 ft 3
Flat Response Curve (SQ):
Sealed 1.25 ft 3
Ported 1 ft 3
Tuning Frequency 32 Hz
Boomer Response Curve (SPL):
Sealed  -
Ported 1.75 ft 3
Tuning Frequency 32 Hz

*Flat response curve (SQ) is geared towards people looking for responsiveness. This style box is loud on all frequencies, generates little impedance loss, and can utilize an amplifier rated at the same RMS as the subwoofer.

*Boomer response curve (SPL) is geared towards people looking for maximum loudness. This style box will be louder than the flat response curve at some frequencies, has a high impedance rise, and can utilize an amplifier rated at a slightly higher RMS than the subwoofer.

*Enclosure recommendations do not account for subwoofer, bracing, and port displacement.

Details

Built to bring you the bass you need without breaking the bank you love, the CT Sounds Tropo 12 Inch 650W RMS Car Subwoofer allows you to peer into the atmospheric pressure CT Sounds subwoofers are capable of. Whether you want to fill in the lows in your stereo or drive the neighbors up a wall; the CT Sounds Tropo 12 is the perfect match.

The subwoofer features a 2.5 inch - 4 layer high-temperature copper voice coil, double slug Y30 grade optimized motor, stamped steel basket, flexible high foam surround, dual round weaved copper tinsel leads, and a premium grade spider pack. Boasting a conservative rating of 650 Watts RMS, this 12-inch subwoofer was engineered to be a harmonious combination of price and performance without a compromise on quality.

Looking to show your friends what real bass sounds like? You have come to the Troposphere; bass yourself seven miles up in the atmosphere with explosive sound pressure, the CT Sounds Tropo 12 Inch Subwoofer fills in the bass missing from your current stereo.

Quick Facts:
RMS Power: 650 Watts
MAX Power: 1300 Watts
Voice Coil Configuration: Dual 4 Ohm
Push Terminal Size: 12 Gauge
Specs
General Specifications:
Product Type: Car Subwoofer
Subwoofer Size: 12"
Voice Coil Configuration: Dual 4 Ohm
RMS Power: 650 Watts
MAX Power: 1300 Watts
Voice Coil Type: 2.5 Inch - 4 Layer High-Temperature Copper Voice Coil
Magnet Type: Double Stacked Y30 Ferrite Magnet
Bottom Plate Type: Signature Chrome Low Carbon Iron Bottom Plate
Surround Type: Dual White Stitched High Narrow Foam Surround
Cone Type: Composite Paper with 3% Carbon Fiber Reinforcement
Tinsel Lead Type: Dual Round Weaved Copper Tinsel Leads
Terminal Type: 12 Gauge Push Terminals
Basket Type: Stamped Steel
Spider Material: Poly-Cotton Blend
T/S Parameters:
Qes: 0.662
Qms: 5.79
Qts: 0.594
Fs: 34.1 Hz
Vas: 43.77 L
Mms: 198.85 g
Cms: 0.11 m/N
Re: 1.8 Ω
Bl: 10.77 Tm
Le: 0.808 mH
Sd: 530.93 cm²
Xmax - Single Way (mm): 11 mm
Xmax - Single Way (cm): 1.1 cm
Vd (Sd*Xmax): 584.02 cm³
SPL: 88.21 dB
Box Specs
Subwoofer Measurements:
Cutout diameter 10.98"
Overall diameter 12.82"
Mounting depth 6.26"
Box Specifications:
Port Area 32 in 2
Displacement 0.13 ft 3
Flat Response Curve (SQ):
Sealed 1.25 ft 3
Ported 1 ft 3
Tuning Frequency 32 Hz
Boomer Response Curve (SPL):
Sealed  -
Ported 1.75 ft 3
Tuning Frequency 32 Hz

*Flat response curve (SQ) is geared towards people looking for responsiveness. This style box is loud on all frequencies, generates little impedance loss, and can utilize an amplifier rated at the same RMS as the subwoofer.

*Boomer response curve (SPL) is geared towards people looking for maximum loudness. This style box will be louder than the flat response curve at some frequencies, has a high impedance rise, and can utilize an amplifier rated at a slightly higher RMS than the subwoofer.

*Enclosure recommendations do not account for subwoofer, bracing, and port displacement.

Wiring Calc.
Subwoofer Quantity
Voice Coil Impedance

Customer Reviews

Based on 67 reviews
96%
(64)
3%
(2)
0%
(0)
0%
(0)
1%
(1)
C
Chris (Chicago, IL)
Amazing value, highly recommended

I’ve had this sub for 8 months and came back just to say how good it is. I’ve had it in a suv and sedan and it performs great in both. Currently have it running off a skar amp and q bomb enclosure. Only have it at 50% and that’s a perfect level, turning it up any more for me is way to much.

I
Indio S. (Holland, MI)
Crazy bang for your buck

Just built a box for one of these and broke a window while doing break in frequency sweeps. Great sound quality and crazy loud.

C
Chris (Weatherford, TX)
Nice subs

I was impressed with them right out of the box. They are nice. Budget friendly and they bang. Would buy again

J
James

Sounds amazing in the curved enclosure built for it!!

D
Dennis M. (Chicago, IL)

So far very happy with the tropo 12” sub sounds freaking awesome hooked up to a Massive 500 watt amp
