CT-7EQ // 7 Band 1/2 Din Parametric Car Audio Equalizer with AUX Input

The CT-7EQ is a 7 band 1/2 din parametric car audio equalizer designed to divide and enhance the segment of frequency for your car audio application. The car audio equalizer features 7 bands that divide 20Hz - 20kHz into 7 segments. Each knob can control the volume of each segment so that you can take full control over your system.

Included with the car equalizer are installation brackets and hardware.

Technical Specifications:

1. Parametric Equalizer : 50Hz, 125Hz, 315Hz, 750Hz, 2.2KHz, 12KHz

2. Boost/Cut Range : ± 18dB

3. S/N Ratio: 90dB

4. Frequency Response : 10Hz-30KHz ±3dB

5. Power Source: 10-14.4V

6. Input Current : .05A Max

7. Distortion : 0.01% THD at 1V Output

8. Output Voltage: 8.1V
9. Output Level : +16 dB

10. Separation : >60dB

11. Bass Adjust : ±10dB

12. Mid Adjust : ±10dB

13. Treble Adjust: ±10dB

14. Sub Bass : 43Hz & 60Hz

15. SD/USB : No
