Meso 5.25 Inch Coax
$89.99
$112.49
Meso 5.25 Inch Coax
$89.99
$112.49
ADDITIONAL 15% DISCOUNT - USE NCAA15 at CHECKOUT!!!
CT Sounds introduces Meso 5.25 inch Coax Speakers (Pair) for your car audio system. Each 2-way speaker has got high-quality glass-fiber cone that generates crystal clear and crisp sound. On top of that, NBR (Nitrile Butadiene Rubber) surround feature allows the speaker to go for a clearer & louder tones. Plus, there is a 25mm silk dome tweeter in the middle of the woofer that makes the high-frequency responses richer, better and stronger.
What's in the box:
- 2 x Meso 5.25" Coaxial speakers
- 2 x 5.25" Woofer Protection Grilles
Features:
- Each speaker has PC+NOMEX spider with 6mm top plate and 5mm backplate
- Voice coil of 1.4” (diameter) at each speaker
- Each speaker has Y30 graded ferrite magnet
- Each speaker has a 25mm silk-dome tweeter which is covered with silver chrome plated face grille and is attached with Copper Clad Aluminum Wire pair (CCAW)
- Each speaker has got steel basket
- Black powder paint on the speakers
Technical Specifications:
- Speaker size: 5.25”
- Speaker type: Coaxial
- System total power: 100W (RMS) | 200W (MAX)
Woofer:
- Rated power per speaker: 50W (RMS) | 100W (MAX)
- Rated power per speaker pair: 100W (RMS) | 200W (MAX)
- Voice coil: 1.4" (diameter)
- Rated impedance: 4Ω (Ohms)
- Sweep voltage: 12V
- Output SPL (@ 1w/1m): 86dB
- Resonant frequency: 88Hz
- Frequency response (@ SPL -10dB): 50Hz – 18kHz
- Magnet weight: 21oz
- Magnet type: Y30 ferrite
Tweeter:
- Rated Impedance: 4Ω (Ohms)
- Sweep voltage: 2.8V
- Tweeter size (diameter): 25mm
- Tweeter type: Silk-dome with metal mesh & face grille
- Magnet type: Neo
Crossover:
- Crossover circuit: 2.2μF capacitor / 100V
- Filter for tweeter: 6dB
Mounting / Installation Parameters:
- Cutout diameter: 115.24mm / 4.5"
- Outer diameter: 158mm / 6.2"
- Mounting depth: 67.5mm / 2.7"
