STRATO-12 // 1250 Watts RMS 12 Inch Car Subwoofer

Regular price 23% OFF Before: $299.99 Sale pricePrice: $229.99
/
$229.99
COIL CONFIGURATION
Details

The coveted Strato-12-D2 12 Inch Car Subwoofer provides a conservatively rated 1250 Watts RMS of sub-bass destruction. Can you handle the feeling of the Stratosphere in your car? The newest Strato-12 version utilizes a basket with increased spider landing space and was designed using competition mega foam surround, vastly improving the Xmax and excursion.

The subwoofer features a 3 inch - 4 layer high-temperature copper-clad aluminum voice coil, 170 oz double stacked Y35 grade ferrite magnet, die-cast aluminum basket, competition mega foam surround, dual round weaved copper tinsel leads, and a premium grade spider pack. Boasting a conservative rating of 1250 Watts RMS, this 12-inch subwoofer was engineered to savor the sonic euphoria that can only be achieved with a Strato Subwoofer.

Looking to fill in the lows with a little extra for show? You have come to the Stratosphere; bass around the clock because you’ll be the loudest on the block, the CT Sounds Strato 12 Inch Subwoofer adds the decibels without the added cash.

Quick Facts:
RMS Power: 1250 Watts
MAX Power: 2500 Watts
Voice Coil Configuration: Dual 2 Ohm
Push Terminal Size: 8 Gauge
Specs
General Specifications:
Product Type: Car Subwoofer
Subwoofer Size: 12"
Voice Coil Configuration: Dual 2 Ohm
RMS Power: 1250 Watts
MAX Power: 2500 Watts
Voice Coil Type: 3 Inch - 4 Layer High-Temperature CCAW Voice Coil
Magnet Type: Double Stacked Y35 Ferrite Magnet
Bottom Plate Type: Signature Chrome Low Carbon Iron Bottom Plate
Surround Type: Dual White Stitched Competition Mega Foam Surround
Cone Type: Composite Paper with 4% Carbon Fiber Reinforcement
Tinsel Lead Type: Dual Round Weaved Copper Tinsel Leads
Terminal Type: 8 Gauge Push Terminals
Basket Type: Cast Aluminum
Spider Material: Poly-Cotton + Nomex Blend
T/S Parameters:
Qes: 0.597
Qms: 6.79
Qts: 0.549
Fs: 31.1 Hz
Vas: 22.14 L
Mms: 371 g
Cms: 0.07 m/N
Re: 1 Ω
Bl: 11.03 Tm
Le: 0.77 mH
Sd: 471.44 cm²
Xmax - Single Way (mm): 15 mm
Xmax - Single Way (cm): 1.5 cm
Vd (Sd*Xmax): 707.16 cm³
SPL: 84.52 dB
Box Specs
Subwoofer Measurements:
Cutout diameter 11.14"
Overall diameter 12.90"
Mounting depth 7.20"
Box Specifications:
Port Area 32 in 2
Displacement 0.16 ft 3
Flat Response Curve (SQ):
Sealed 1 ft 3
Ported 1.50 ft 3
Tuning Frequency 32 Hz
Boomer Response Curve (SPL):
Sealed  -
Ported 1.75 ft 3
Tuning Frequency 32 Hz

*Flat response curve (SQ) is geared towards people looking for responsiveness. This style box is loud on all frequencies, generates little impedance loss, and can utilize an amplifier rated at the same RMS as the subwoofer.

*Boomer response curve (SPL) is geared towards people looking for maximum loudness. This style box will be louder than the flat response curve at some frequencies, has a high impedance rise, and can utilize an amplifier rated at a slightly higher RMS than the subwoofer.

*Enclosure recommendations do not account for subwoofer, bracing, and port displacement.

Details

The coveted Strato-12-D4 12 Inch Car Subwoofer provides a conservatively rated 1250 Watts RMS of sub-bass destruction. Can you handle the feeling of the Stratosphere in your car? The newest Strato-12 version utilizes a basket with increased spider landing space and was designed using competition mega foam surround, vastly improving the Xmax and excursion.

The subwoofer features a 3 inch - 4 layer high-temperature copper-clad aluminum voice coil, 170 oz double stacked Y35 grade ferrite magnet, die-cast aluminum basket, competition mega foam surround, dual round weaved copper tinsel leads, and a premium grade spider pack. Boasting a conservative rating of 1250 Watts RMS, this 12-inch subwoofer was engineered to savor the sonic euphoria that can only be achieved with a Strato Subwoofer.

Looking to fill in the lows with a little extra for show? You have come to the Stratosphere; bass around the clock because you’ll be the loudest on the block, the CT Sounds Strato 12 Inch Subwoofer adds the decibels without the added cash.

Quick Facts:
RMS Power: 1250 Watts
MAX Power: 2500 Watts
Voice Coil Configuration: Dual 4 Ohm
Push Terminal Size: 8 Gauge
Specs
General Specifications:
Product Type: Car Subwoofer
Subwoofer Size: 12"
Voice Coil Configuration: Dual 4 Ohm
RMS Power: 1250 Watts
MAX Power: 2500 Watts
Voice Coil Type: 3 Inch - 4 Layer High-Temperature CCAW Voice Coil
Magnet Type: Double Stacked Y35 Ferrite Magnet
Bottom Plate Type: Signature Chrome Low Carbon Iron Bottom Plate
Surround Type: Dual White Stitched Competition Mega Foam Surround
Cone Type: Composite Paper with 4% Carbon Fiber Reinforcement
Tinsel Lead Type: Dual Round Weaved Copper Tinsel Leads
Terminal Type: 8 Gauge Push Terminals
Basket Type: Cast Aluminum
Spider Material: Poly-Cotton + Nomex Blend
T/S Parameters:
Qes: 0.597
Qms: 6.115
Qts: 0.544
Fs: 31.8 Hz
Vas: 22.41 L
Mms: 351.96 g
Cms: 0.071 m/N
Re: 1.66 Ω
Bl: 13.96 Tm
Le: 1.1 mH
Sd: 471.44 cm²
Xmax - Single Way (mm): 15 mm
Xmax - Single Way (cm): 1.5 cm
Vd (Sd*Xmax): 707.16 cm³
SPL: 84.84 dB
Box Specs
Subwoofer Measurements:
Cutout diameter 11.14"
Overall diameter 12.90"
Mounting depth 7.20"
Box Specifications:
Port Area 32 in 2
Displacement 0.16 ft 3
Flat Response Curve (SQ):
Sealed 1 ft 3
Ported 1.50 ft 3
Tuning Frequency 32 Hz
Boomer Response Curve (SPL):
Sealed  -
Ported 1.75 ft 3
Tuning Frequency 32 Hz

*Flat response curve (SQ) is geared towards people looking for responsiveness. This style box is loud on all frequencies, generates little impedance loss, and can utilize an amplifier rated at the same RMS as the subwoofer.

*Boomer response curve (SPL) is geared towards people looking for maximum loudness. This style box will be louder than the flat response curve at some frequencies, has a high impedance rise, and can utilize an amplifier rated at a slightly higher RMS than the subwoofer.

*Enclosure recommendations do not account for subwoofer, bracing, and port displacement.

Wiring Calc.
Subwoofer Quantity
Voice Coil Impedance

Customer Reviews

Based on 56 reviews
96%
(54)
4%
(2)
0%
(0)
0%
(0)
0%
(0)
I
Isaac

Very good speakers

J
JJ R. (Columbus, IN)
Stratos

I just got my stratos in today and they hit hard. i only have them on 2000w right now but they still are louder than the tropos

I
Isaac D. (Visalia, CA)
beefy 12”s 🤯

Didn’t fit in my box which was a bit unfortunate and had to invert it. It had a bit of a burnt smell which scared me to death thinking the coil broke the first day but all round pretty good wiring to 1 ohm will be warm but I think inverting it is the best decision I made because it’ll never be hot

r
r.z. (Arvin, CA)
12’ strato hits hard!!🔥

I have 1 Strato 12 in a Ct1x12 sub box in my accord and it hits hard 🔥have a burnt smell at first but I guess it was just breaking in because it no longer gives that smell. Definitely has my car shaking! Now I’m for sure getting more Ct products 🙏🏾🔥

A
A.W. (Milford, MA)
3 years later.

3 years later and my 12" Stratos are still shaking the ground and houses in the area lol. I paired my to 12s to a taramp smart bass 3k in a sealed enclosure and they still bring a smile to my face. The only not bad thing is when get a prefabricated box is you have to open up the hole cause these subs are not your normal size 12s. I am super happy with ct sounds.
